DIOX™ eChem Chlorine Dioxide Systems
Powerful On-Site Chlorine Dioxide Generation—Safe, Pure and Engineered for Performance.
Advanced On-Site Chlorine Dioxide Generation
Designed and manufactured in Australia by Water Engineers, the DIOX eChem range produces 99.5% pure, pH-neutral Chlorine Dioxide using only Sodium Chlorite, water and electricity—with no acid and no chlorine gas required. Available in capacities from 50 g/hr to 2,000 g/hr, every system provides exceptional performance while significantly reducing chemical handling risks and operating costs.
Whether protecting drinking water, industrial process water or critical healthcare systems, DIOX eChem delivers superior disinfection with outstanding reliability.
Our Products
Book an Appointment
Why Chlorine Dioxide?
Chlorine Dioxide (ClO₂) is recognised worldwide as one of the most effective oxidising biocides available for water treatment.
Unlike traditional chlorine, Chlorine Dioxide works through oxidation rather than chlorination, allowing it to rapidly eliminate harmful microorganisms without forming many of the undesirable by-products associated with conventional disinfection.
ClO₂ effectively destroys:
- Bacteria
- Viruses
- Legionella
- Biofilm
- Algae
- Fungi
- Protozoa
- Waterborne pathogens
Because Chlorine Dioxide remains highly effective across a broad pH range and penetrates biofilm exceptionally well, it continues disinfecting areas where conventional chlorine treatments often fail—including complex pipework and dead-end sections of water distribution systems.
Safe, Pure and Produced On Demand
Concentrated Chlorine Dioxide cannot be safely transported or stored due to its instability.
The DIOX eChem Series solves this by generating Chlorine Dioxide on-site and on-demand, producing a stable dissolved solution of up to 2,000 ppm exactly when required.
The result is:
- No transport of hazardous ClO₂ gas
- No acid storage requirements
- Lower chemical inventory
- Improved operator safety
- Fresh, highly active disinfectant every time
Intelligent Automation
Every DIOX eChem generator incorporates advanced microprocessor control technology that continuously monitors and optimises system performance.
The intelligent controller automatically:
- Monitors operating conditions
- Optimises production efficiency
- Controls chemical generation
- Protects equipment
- Displays system status via LCD display and LED indicators
- Supports remote monitoring and communication options
This fully automated operation provides dependable, unattended performance with minimal operator intervention.
The DIOX eChem Process
At the heart of every DIOX eChem system is the patented OxiMax® CDE Electrolysis Cell.
Using advanced electrochemical technology, Sodium Chlorite is converted directly into high-purity Chlorine Dioxide gas through a highly efficient electrolytic process.
The process follows the reaction:
2 NaClO₂ + 2 H₂O → 2 ClO₂ + 2 NaOH + H₂
The generated Chlorine Dioxide gas is then:
- Produced within the patented OxiMax CDE Cell.
- Separated using the patented vClone™ gas extraction system.
- Dissolved into water.
- Stored as a stable Chlorine Dioxide solution at concentrations up to 2,000 ppm.
- Automatically dosed into the treatment system as required.
Continuous recirculation maximises conversion efficiency while minimising energy consumption, providing outstanding performance from a compact footprint.
Engineered for Reliability
The DIOX eChem Series has been designed for long service life and minimal maintenance.
Each patented electrolysis cell features:
- Computer-optimised hydraulic flow paths
- Long-life Titanium SC12 coated anodes
- Titanium cathodes
- Heavy-duty aluminium backing plates for strength and cooling
- High-efficiency continuous operation
Available as wall-mounted or floor-mounted systems, the compact design minimises installation space while simplifying servicing and maintenance.
Typical Applications
The DIOX eChem Series is ideally suited to:
- Municipal drinking water treatment
- Hospitals and healthcare facilities
- Legionella prevention programs
- Cooling towers
- Hot and cold water systems
- Food and beverage processing
- Wineries and breweries
- Industrial process water
- Wastewater treatment
- Mining operations
- Irrigation systems
- Aquaculture
- Swimming pools
- Pharmaceutical manufacturing
Ideal for Legionella Control
Legionella bacteria can survive within biofilm and dead-end pipework where chlorine often struggles to penetrate.
Chlorine Dioxide rapidly penetrates biofilm and remains effective throughout entire water distribution systems, making it one of the preferred disinfectants for:
- Hospitals
- Aged care facilities
- Hotels
- Commercial buildings
- Cooling towers
- Large water distribution networks
Superior Water Quality
Unlike conventional chlorination, Chlorine Dioxide delivers powerful oxidation without significantly affecting water quality.
Benefits include:
- No chlorine taste or odour
- Minimal formation of chloramines
- Significantly reduced Trihalomethanes (THMs)
- Excellent oxidation of iron and manganese
- Effective removal of phenols and organic compounds
- Improved colour and taste control
This makes Chlorine Dioxide particularly valuable for flavour-sensitive industries including wineries, breweries and beverage production.
Key Benefits of DIOX eChem™
- 99.5% pure Chlorine Dioxide generation
- Acid-free operation
- Single precursor chemistry
- Generates up to 2,000 ppm solution
- Continuous on-demand production
- Compact Australian-designed equipment
- Low operating costs
- Minimal maintenance
- High conversion efficiency
- Advanced automated controls
- Safe on-site generation
- Remote monitoring capability
- Patented Australian technology
Customised to Your Application
Every water treatment system is different.
The DIOX eChem range can be configured with:
- Remote communication systems
- Automated dosing pumps
- Residual chlorine dioxide analysers
- Process control equipment
- PLC integration
- Custom monitoring packages
- Application-specific control systems
This flexibility allows Water Engineers to deliver a complete Chlorine Dioxide solution tailored to each installation.
DIOX eChem™ vs Conventional Acid–Chlorite Systems
| DIOX eChem™ | Traditional Acid–Chlorite Systems |
|---|---|
| No acid required | Requires hazardous acid |
| Safer chemical handling | Higher operator risk |
| Single precursor chemistry | Multiple chemical storage |
| Lower maintenance | Greater maintenance requirements |
| High purity ClO₂ | Lower purity generation |
| Fully automated | More manual intervention |
| Lower operating costs | Higher chemical consumption |
| Reduced environmental risk | Greater hazardous chemical management |
Chlorine Dioxide vs Chlorine
| Chlorine Dioxide | Chlorine |
|---|---|
| Superior biofilm penetration | Limited biofilm penetration |
| Highly effective against Legionella | Less effective |
| Effective across a wide pH range | Performance decreases at higher pH |
| Minimal THM formation | Produces THMs |
| Does not form chloramines | Produces chloramines |
| Better taste and odour control | Can affect taste and smell |
| Powerful oxidiser | Chlorinating disinfectant |
| Excellent for complex water systems | Reduced effectiveness in dead-end systems |
Australian Engineered. Globally Trusted.
The DIOX eChem™ Chlorine Dioxide Series combines patented Australian engineering with advanced electrochemical technology to provide one of the safest, most efficient and cost-effective Chlorine Dioxide generation systems available.
Whether protecting public health, improving industrial water quality or ensuring regulatory compliance, DIOX eChem delivers dependable on-site Chlorine Dioxide generation—when you need it, where you need it.
+(61) 7 55716 690
Need more help?
Have Complex Questions? Let’s Explore Them Together
We provide ongoing technical support and maintenance services to ensure your water treatment system continues to perform at its best.
Our dedicated support team provides fast and efficient ticket-based assistance to help resolve issues and minimise downtime.
We offer free expert insights and advice to help you identify the most effective water treatment solution for your application.
common Questions
Explore Common Questions About DIOX eChem™ products.
What is the DIOX eChem™ Chlorine Dioxide System?
The DIOX eChem™ Series is an advanced on-site Chlorine Dioxide (ClO₂) generation system that produces up to 99.5% pure, pH-neutral Chlorine Dioxide using only Sodium Chlorite, water and electricity. The system eliminates the need for hazardous acids while providing safe, reliable and highly effective water disinfection.
How does the DIOX eChem™ system work?
Does the DIOX eChem™ system require acid?
Why is on-site Chlorine Dioxide generation preferred?
The DIOX eChem™ Series produces up to 99.5% pure, pH-neutral Chlorine Dioxide at concentrations of up to 2,000 ppm, delivering exceptional oxidation and disinfection performance.
What are the advantages of Chlorine Dioxide over chlorine?
Chlorine Dioxide provides superior biofilm penetration, excellent Legionella control, remains effective across a wider pH range, produces significantly fewer disinfection by-products such as THMs, and does not form chloramines that affect water taste and odour.
What applications is the DIOX eChem™ system suitable for?
The system is ideal for:
- Drinking water treatment
- Cooling towers
- Hospitals and healthcare facilities
- Legionella control
- Food and beverage processing
- Wineries and breweries
- Industrial process water
- Wastewater treatment
- Mining operations
- Aquaculture
- Irrigation systems
Can the system help control Legionella?
Yes. Chlorine Dioxide is recognised as one of the most effective disinfectants for controlling Legionella because it penetrates biofilm and remains active throughout entire water distribution systems, including dead-end pipework.
Is the DIOX eChem™ system fully automatic?
Yes. Every system features intelligent microprocessor control that continuously monitors operating conditions, optimises production, protects the equipment and provides real-time system status via an LCD display and LED indicators.
What production capacities are available?
The DIOX eChem™ Series is available in outputs ranging from 50 g/hr to 2,000 g/hr, making it suitable for small commercial installations through to large industrial and municipal water treatment facilities.
Is remote monitoring available?
Yes. Optional remote communication, PLC integration, dosing control and monitoring systems allow operators to remotely monitor system performance and receive operational status updates.
Is the DIOX eChem™ system energy efficient?
Yes. The patented recirculation process maximises chemical conversion while minimising power consumption, providing industry-leading efficiency from a compact footprint.
What chemicals are required?
Only one chemical is required:
- 25% or 31% Sodium Chlorite
No acid, chlorine gas or additional chemical activators are required.
Is the system easy to maintain?
Yes. The DIOX eChem™ Series features long-life titanium electrodes, optimised hydraulic design and a compact layout that minimises routine maintenance and maximises operational reliability.
Why choose DIOX eChem™?
The DIOX eChem™ Series combines patented Australian engineering with advanced electrochemical technology to deliver:
- Safe acid-free operation
- High-purity Chlorine Dioxide generation
- Low operating costs
- Intelligent automation
- Reliable continuous production
- Compact installation
- Proven long-term performance
- Customisable solutions for virtually any water treatment applicatio
